Portax Long Series

Portax Series

Portax-LSR

The Portax Large series exemplifies generosity of space in a moderately sized horse trailer. Designed for vehicles that can tow 2500kg/5512lbs, the Portax L models are extensions of the regular Portax models, seen on the regular Portax series page.

Each Portax L model offers a different saddle storage, and utility of the extended 65cm/26″ of additional length. The Portax LE, LK and LSKA models leave room for additional hay bales at the front of the trailer, offer the same great saddle storage of their regular-size counterparts and allow the rider a change space within the horse stall.

The Portax LSR has an innovative small tack room design with shelving, boot jack, seating, saddle racks and more. This trailer is designed for horses up to 16.2hh.

Finally, the Big Portax completes the Large Portax series, providing the most generous of horse stalls and the largest tack room of all Böckmann 2 horse trailers. Also exhibiting some of the key storage features found in the LSR model…but to Big Portax dimensions!

Choose from 11 standard colours to customize your trailer’s polyester parts, add a decor by Jan Kuenster, or pick an accessory to make your life on the road easier. Böckmann makes it easy to be efficient and look good doing it!

Standard Features: Portax LE

The Portax LE allows even more room to work around your horses while on the trailer. Saddling, grooming, adding travel bandages/shipping boots can all be accomplished easily. Double lateral windows on each side of the trailer creates an even airier space. Comfortable access to the saddle chest from each side of the trailer, with the freely rotating saddle carousel makes life simpler. The added portable feed/water buckets mounted on each side wall is one less item to pack!



Chassis:

Built from hot-dipped galvanized steel chassis, the Portax LE also rides on the World Class Suspension Chassis System (WCF- Plus) – a coil Spring suspension with added shocks, and rubber damper for an ultra smooth ride for the horse. An automatic jockey wheel mounted on an integrated lockable 2″ coupler allows the rider to easily raise or lower the chassis frame for hitching purposes and moving the trailer by hand around the yard.

Body:

Same great body features of the Portax E, this longer version of its regular size cousin offers 2 portable bucket feed mounting places and an access door on each side of the trailer. Extra floor space between the chest bars and the saddle storage allow you to bring hay or add a large trunk.  Two lateral windows on each side of the trailer + roof vent = great air flow!

Internal Space:

This longer version of the regular Portax K Model is perfect for transporting larger horses. The additional 63cm ahead of the chest bar allows the larger horse to step forward and swing across the front of the trailer to exit out the forward ramp.. The additional floor space also offers room to take additional hay or a larger tack trunk!

The Saddle cupboard contains 2 tubular steel saddle racks suitable for English or Western saddles, hooks, 1 net + 2 mirrors on the door, a broom with telescopic handle and a plastic shovel.



Standard Features: Portax LK

Extended version of the Portax K , this model offers a door on each side of the trailer

Chassis:

Built from hot-dipped galvanized steel chassis, the Portax LK also rides on the World Class Suspension Chassis System (WCF- Plus) – a coil Spring suspension with added shocks, and rubber damper for an ultra smooth ride for the horse. An automatic jockey wheel mounted on an integrated lockable 2″ coupler allows the rider to easily raise or lower the chassis frame for hitching purposes and moving the trailer by hand around the yard.

Body:

Same great body features of the Portax K, this longer version of its regular size cousin offers 2 portable bucket feed mounting places and an access door on each side of the trailer. The front walk-off ramp is farther forward on this model allowing more room for larger horses to exit out the front of the trailer. Two lateral windows on each side of the trailer + roof vent = great air flow!

Internal Space:

This longer version of the regular Portax K Model is perfect for transporting larger horses. The additional 63cm ahead of the chest bar allows the larger horse to step forward and swing across the front of the trailer to exit out the forward ramp.. The additional floor space also offers room to take additional hay or a larger tack trunk!

The Saddle cupboard contains 2 tubular steel saddle racks suitable for English or Western saddles, hooks, 1 net + 2 mirrors on the door, a broom with telescopic handle and a plastic shovel.

Standard Features: Portax L SKA

External + Stall Access to Tack Cupboard in this extended version of the regular Portax SKA

Chassis:

Built from hot-dipped galvanized steel chassis, the Portax L SKAl also rides on the World Class Suspension Chassis System (WCF- Plus) – a coil Spring suspension with added shocks, and rubber damper for an ultra smooth ride for the horse. An automatic jockey wheel mounted on an integrated lockable 2″ coupler allows the rider to easily raise or lower the chassis frame for hitching purposes and moving the trailer by hand around the yard.

Body:

Same great build as the Portax SKA, the L-version extends the body a further 63cm, offering 2 access doors into this trailer and feed bucket mounts on each side of the trailer. Two lateral windows on each side of the trailer + roof vent = great air flow!

Internal Space:

The inner stall offers padded walls and a bright white roof colour. Two 33″ stalls comfortably fit the most generous girth of horses to 18hds. The rubber flooring is glued and sealed to the aluminum floor beneath. The loading ramp is covered with rubber integrated safety treads and side stops – preventing slipping in inclement weather. OFfering all the safety features of the Portax SKA, this longer version offers more room ahead of the chest bar for hay storage or tack/feed trunk storage.
The Saddle cupboard contains 2 tubular steel saddle racks suitable for English or Western saddles, hooks, 1 net + 2 mirrors on the door, a broom with telescopic handle and a plastic shovel, hooks, and blanket rack.

Standard Features: Portax LSR

Full height small Dressing Room in the anterior section of the trailer!

Chassis:

Built from hot-dipped galvanized steel chassis, the Portax LSR also rides on the World Class Suspension Chassis System (WCF- Plus) – a coil Spring suspension with added shocks, and rubber damper for an ultra smooth ride for the horse. An automatic jockey wheel mounted on an integrated lockable 2″ coupler allows the rider to easily raise or lower the chassis frame for hitching purposes and moving the trailer by hand around the yard.

Body:

Following the general build of the regular Portaxes, the LSR model takes advantage of the addiotnal 63cm to create a full dressing space. Two doors allow access to the horse stall. a full wall creates a stall space best suited for horses less than 16.2. Entrance door to the dressing room is from the curbside of the trailer. Additonal windows in the dressing room are possible, as is an optional door between the dressing room and horse stall.

Internal Space:

The inner stall offers padded walls and a bright white roof colour, two lateral sliding windows on each side of the trailer + roof vent makes keeping the environment cool for the horses. Portable feeding troughs can be mounted on each door,

The Dressing Room houses 2 tubular steel swiveling saddle racks suitable for English and Western saddles. More racks can be installed at factory. A flip-up seat and boot jack make preparing for your ride a breeze. Whip holders, feed trough storage, 2 steel shelves, and many hooks, as well as the standard broom and shovel are also on board.

Standard Features: Big Portax WCF

Full Tack Room ahead of Horse Stalls-the most Generous 2 Horse Trailer Yet!
A video clip of a Big Portax WCF with a few Xtras!

Chassis:

The Big Portax offers two 36″ wide stalls, and an internal stall height of 7’9. Built from hot-dipped galvanized steel chassis, the Big Portax WCFrides on the World Class Suspension Chassis System (WCF- Plus) – a coil spring suspension with added shocks, coil and rubber damper for an ultra smooth ride for the horse. An automatic jockey wheel mounted on an integrated lockable 2″ coupler allows the rider to easily raise or lower the chassis frame for hitching purposes and moving the trailer by hand around the yard.

Body:

Anodized aluminum web profile panel side walls – 1800 mm high – always a silver finish-topped with a metallic silver roof & front bow. Different roof colours are available (accessory). The rear loading ramp is a full 6′ in length with gas shocks as lifting assists. Two steps on rear ramp allows you to step up and control the canvas lift. Böckmann anodized aluminum flooring provides strength and longevity. The double web profile keeps the horse stall cool. The trailer front is 6.5′ anteroom with a fiberglass front bow which holds the storage area. A full height groom door on each side enters the horse stalls, and a full height door with window on the curb side enters the Tack Room. Two lateral sliding windows on each side of the horse stalls, and roof vent provide lots of light, and air flow control. Single plastic fenders are standard – with coloured fibreglass fenders and sidebraces as possible options. All trailers for North America come with a mounted full spare wheel

Internal Space:

The inner stall offers padded walls and a bright white roof colour. The rubber flooring is glued and sealed to the aluminum floor beneath. The loading ramp is covered with rubber integrated safety treads and side stops – preventing slipping in inclement weather. An additional rubber mat for wear protection is placed under the front feet of the horses. The Multi-Safe stall bar system + anti-panic stall system allows you to adjust height of the stall bars and the length of the stall. In an emergency the chest and rear bars can be released from outside the trailer. The chest bars have additional black foam bar padding. The transparent PVC partition is mounted on tubular galvanized steel, and can be swiveled to either side to accommodate loading. The extra wide stall will accommodate fully tacked horses .Black lateral kick plates complete the inside stall walls.

Complete with 7 snaffle hooks, 2 saddle racks, a light, a window in the groom door, and a portable step for ease of access, the front storage room can also have an additional window added on the left and an access door between storage room and horse stall. Mirrors, storage nets, broom and shovel are also included..

  • All Böckmann Horse Trailers for Canada include:

    • Galvanized steel chassis
    • Independent torsion suspension
    • All-wheel CFF- Plus shocks
    • All wheel mechanical brakes
    • Multi-Safe System: adjustable bars for stall length and bar height
    • Interior lighting
    • Black kick plates
    • Automatic jockey wheel
    • Clear PVC on tubular steel stall divider
    • Adjustable chest/butt bars
    • Hay net hooks
    • Rubber stall mat glued and sealed to floor
    • Black plastic fenders
    • Spare wheel & cover
    • Ramps covered with Böckmann’s safety treads & side stops

    Trailers are rear ramp-loads, unless otherwise specified.

    Saddle Chest Kits include: broom, shovel, net, & mirror on door.
