Big Champion R

The Big Champion R  is the entry-priced trailer for horses to 18hh! A generous horse trailer with saddle storage,  choose between an English tack or Western tack model. Suited for horses up to 18h, the stalls are 33′ wide with a longer space ahead of the chest bar for more head and neck space for the larger horse. Consider one of Böckmann’s many standard colours for your roof & front bow, add an external tie bar or folding mounting step.  GVWR of 2400kg/5291lbs.[/text][button text=”Specifications” type=”fill” size=”large” shape=”dima-btn-no-rounded” color_class=”di_red” lightbox=”” href=”https://www.maplelanetrailers.com/trailer-specifications/” title=”” popup_content=”” id=”” class=”” style=””]

[youtube title=”Big Champion R WCF” video=”https://youtu.be/enO7hRLvVck” iv_load_policy=”true” autohide=”Default” controls=”Always”]
[text]

Trailers in Stock

[/text]

[button text=”See All Big Champion R Trailers” type=”stroke” direction=”” color_class=”di_red” float=”start” icon_fontawesome=”fa fa-caret-right” lightbox=”” href=”https://www.maplelanetrailers.com/product-category/champion-series/big-champion-wcf/” title=”” popup_content=”” id=”” class=”” style=””]
[text]

What Makes the Big Champion R Unique?

Seeking a larger trailer for your larger horses, want to buy a quality trailer, but need to be considerate of your pocket book? The Big Champion is for you. Built on the same size chassis as the Portax series, the Big Champion costs a little less. Offering the same stall space for the horses that wear up to an 84″ blanket in the standard design, the Big Champion walls are only 5’tall, padded and protected by lateral kick plates.    Rear ramp entry, one escape door for you, a roomy tack cupboard and all of Böckmann’s safety features for your horses – the Big Champion is an excellent choice![/text]

[tab_nav model=”” id=”” class=”” style=””][tab_nav_item active=”true” title=”Standard Package” id=”” class=”” style=””][tab_nav_item title=”Additional Features” id=”” class=”” style=””][tab_nav_item title=”Dimensions” id=”” class=”” style=””][tab_nav_item title=”Floor” id=”” class=”” style=””][tab_nav_item title=”Braking” id=”” class=”” style=””][/tab_nav][tabs id=”interior” class=”” style=””][tab active=”true” class=”” style=””]

  • two 33″wide stallsBig Champion and horse
  • pop-out tinted windows
  • single black plastic fenders
  • simple stall bar fastening with 3-angled rear positions/2 chest bar positions
  • chest bars covered in black foam padding
  • side wall padding
  • lateral black kick plates
  • stall divider with clear PVC curtain
  • solid PVC rear storm curtain with integrated wind screen
  • rear ramp entry with Böckmann patented integrated rubber treads and side stops



[/tab][tab class=”” style=””]

big
Champion R English
Champion R Western
Champion R Western

The Champion R – English:

  • chest bar positions at heights suitable for warmbloods (2 settings)
  • English Saddle chest: 2 adjustable telescopic saddle racks

The Champion R- Western:

  • chest bar positions are lowered to better accommodate breeds (2 settings), such as Quarter Horses, Gaited Horses, Paso-Finos, Arabs, Haflingers
  • Western Saddlechest: 2 fixed position tubular formed racks for Western Saddles

[/tab][tab class=”” style=””]

GVWRTotal HeightTotal WidthTotal LengthInternal HeightInternal WidthInternal LengthHead SpacePayloadLTW
Big Champion R (English/Western) 5291 lbs 2400kg 9’ 2755mm 7’ 7” 2350mm 15’6” 4726mm 7’8” 2350mm 5’ 9” 1750mm 11’ 2” 3415mm 56” 1422mm 3088 lbs 1401 kg 211 lbs 96 kg

Compare Specs[/tab][tab class=”” style=””]

  • Aluminum floor: extruded click floor panels made from robust double web profiRubber Matles. This keeps road heat away from horses feet and legs.
  • Rubber mat is fully glued to floor and sealed to wall edgeshorse loading

[/tab][tab class=”” style=””]

  • Locking North American 2″ couplers ensure you stay safely connected.
  • The superior overrun brakingsystem stops every time without ever pushing the tow vehicle.

Braking System

[/tab][/tabs]

[text]

Chassis

The Champion R has a galvanized steel chassis frame. The steel chassis secures the aluminum floor panels. Under the floor, there are longitudinal bars as well as cross-member pieces to provide the greatest strength.[/text]

[image lightbox=”” width=”” is_gallert_item=”” src=”5176″ alt=”” href=”” title=”” popup_content=”” id=”” class=”” style=””]
[text]

Interior

The Big Champion R for has two 33” wide stalls + 7’6” internal height. The saddle chest sits in the nose of the trailer. Two tinted pop-out windows allow air to flow into the trailer. A hay ring centered in the roof and a bracket on top of the saddle chest offer different positions to tether hay bags or hay nets. Rings for trailer ties are found at the level of the chest bar.  This allows the horses to lower their heads for balance and clear their sinuses.[/text]

[text]

Big Champion R-Western:
holds horses wearing 84″ blankets

Open wing Door on trailer
Example of Rear Door-Ramp Combo in the open Wing Door Position

 [/text]

[text]

Champion R – English:
holds horses wearing 84″ blankets

Champion Horse Trailer
Rear Ramp of Champion R Horse trailer with canvas screen showing wind screen open

[/text]

[text]

Trailer Features

Although features can be added to trailers, there are standard features on Böckmann Horse Trailers.[/text][button text=”Böckmann Features” type=”fill” size=”large” shape=”dima-btn-no-rounded” color_class=”di_red” lightbox=”iframe” href=”https://www.maplelanetrailers.com/bockmann-features/” title=”” popup_content=”” id=”” class=”” style=””]
